VIDEO LIGHTING

FX Roadlights

The SkyPanel Family. Different sizes for different applications.

SkyPanel is available in several sizes: the S30, S60, S120, and S360. The S60 is a mid-range model, featuring a light aperture of 645 x 300 mm and accommodating the vast majority of applications. The S120 is twice as long as the S60, but weighs nearly the same. Its larger light aperture makes a great soft light even better. The S30 is a smaller, more portable version; half the length of the S60, it is perfect for on-the-go mobile applications. The S360 is the largest and brightest SkyPanel with four times the output of the S60 and almost six times the aperture size. The S360 is perfect for lighting large areas with tuneable, soft light. S30 and S60 models are available in fully color tuneable and remote phosphor versions.

Unlike other tuneable fixtures, SkyPanel makes no sacrifice when it comes to light output. SkyPanel puts out a tremendous amount of light, in a soft and uniform beam field. Brighter than a 2 kW tungsten soft light or a 6 kW tungsten space light, the SkyPanel S60 has more than enough light for most applications. At the same time, the lamphead is able to perform beautifully at lower light levels. This range of illumination and color gives users an unprecedented amount of control.

Made in Germany to the high standards for which all ARRI products are known, SkyPanel is built to last – constructed from resilient materials and assembled by hand with great care. Other features include an on-board battery input for mobile applications, LAN port for network connectivity, USB-A port for firmware updates via thumb drive, and many more.

FX Roadlights

The LS 1200d Pro LED Light from Aputure is a powerful COB LED fixture with expansive power, control options, and output comparable to a 1200W HMI, augmented by its 55° Hyper Reflector. The precision fixture has a solid 5600K color temperature with a high CRI/TLCI rating of 95 that is great for location shooting outdoors, or in areas dominated by

Key Features
• Color: 5600K, CRI/TLCI: 95
• 15, 30, 55° Beam Angle w/ Reflector
• Wireless DMX, Bluetooth Control
• 4 Dimming Modes, Comparable to 1200W HMI

FX Roadlights

Aputure LS 600d Pro (V-Mount)

Aputure LS-600d Pro Overview

The LS 600d Pro Light Storm Daylight LED Light from Aputure is a powerful COB LED fixture with expansive power, control options, and output comparable to a 1200W HMI, augmented by its 55° Hyper Reflector. The precision fixture has a solid 5600K color temperature with a high CRI/TLCI rating of 96 that is great for location shooting outdoors, or in areas dominated by other daylight-balanced fixtures such as HMIs. Besides power, control is a driving force in the design of the 600d Pro. The light also has a myriad of wireless control methods, such as the included 2.4 GHz remote, the Sidus Link mobile app, and the built-in wireless DMX control. It has four dimming curves: Linear, Exponential, Log, and S-Curve, to ensure accuracy regardless of your chosen brightness level. While you can make adjustments locally on the fixture, you can also make them wirelessly at a distance up to 328′ via these methods – a real attribute for lights mounted overhead or in hard to reach places.

Powering the light has options too. The light is ready for worldwide use via its 100 to 240V power supply but thanks to its dual battery plate it can be powered by two 14.4V, 26V, or 28.8V batteries. The control box also accepts 48V (15A) DC power via a 3-pin XLR for external power stations. You can use two V-Mount mount batteries and recharge them while they are connected to the plugged-in light.

The 600d Pro is weatherproof (dust and water resistant), so it is built to withstand any shooting environment. When it comes to features Aputure has left no stone unturned with the inclusion of special effects such as Paparazzi, Fireworks, Lightning, Faulty Bulb, TV, Pulsing, Strobe, and Explosion. Aputure has also generously provided a rolling case for storage and transport.

FX Roadlights

Aputure LS 300X “Bi-Color

The 300x is Aputure’s latest flagship Light Storm LED fixture, finally integrating properly mixed variable-white lighting into an easily modifiable point-source light engine. The 300x features a specially designed color-blending optical element in front of its LED light source, combining the bi- color chipset into one cohesive point-source. The combination of this new technology, along with the Aputure ecosystem, allows you to achieve bi-color flexibility never before experienced with Aputure products.

FX Roadlights

Aputure AMARAN 200D

200W Daylight-Balanced LED

CREATIVES REJOICE

The Amaran 200d is a daylight point-source LED fixture with stunning brightness and wireless Bluetooth app control. Amaran provides the ultimate lights for content creators, interviews, portrait photography and video production.

FX Roadlights

Reflect 2′ 2-Bank offers double the output of the original Pipeline Remote Phosphor fixture. You get the same great quality lighting drawing 40 watts but with an output of 6,000 Lumens. Available in 3200k, 4300k or 5600K. it comes with a 3-Pin XLR male mounted in the end. The 2-Bank comes with a full length adjustable locking yoke with tvmp. Optional 3-Pin XLR Cables with high quality wire and insulation are available in 3 lengths; 8′, 15′ and 25′. You can power 4 of the 2-Bank Reflect fixtures with the optional 4-Way Controller with 4 each 40 watt channels. An optional world power supply with Locking AC cable is available when you want to use AC power with the optional 40 watt inline Driver/Dimmer with a female 3-Pin XLR which comes with a d-tap cable included for 14.4 VDC battery operation.

FX Roadlights

SL1 SWITCH
It all started with the SL1. It was created to find an alternative LED solution to the fluorescent tube (which we loved incidentally). We wanted to design a light which would be robust, compact, colour changing and dimmable. That would also incorporate a soft and round light source in a lightweight and durable housing. Together with a broad range of diffusion and rigging accessories this fixture is autonomous and versatile. The Dome, which creates an even softer effect is DMG’s users favourite accessory. The SL1 SWITCH is the foot soldier, it brings security and comfort on set.

FX Roadlights

CRI/TLCI 95

Flicker free at any frame rate, shutter, angle or intensity

100-0% smooth dimming.

Optional Bluetooth, DMX and wireless DMX modules

Primary/Replica configuration via XLR for single control of multiple fixtures

Passive or active cooling for silent operation

46° Beam Angle

Multi-voltage 100-240AC; DC input 13V to 24V

Wide range of light shaping and modifying accessories

Optional Gold Mount and V-Mount battery plates.

Weight: 3.2kg

FX Roadlights

The Gaffer’s Kit is the most comprehensive of all the LitePad kits. The Gaffer’s Kit provides a versatile and extensive set of lighting tools, including: ten LitePad Axiom 90 LED fixtures (two of each size), two 3″ Round LitePad HO90 units, and a wide range of mounting, power and light-control accessories. If you need the options and accessories generally required on film sets, this is the kit for you.

FX Roadlights
