LED LIGHTING

FX Roadlights

Source Four LED Series 2 Daylight HD and Tungsten HD arrays are designed for broadcast lighting, offering flicker-free operation and high-definition lighting. With a new mix of LED emitters, the luminaires’ output is significantly brighter than the original Source Four LED white-light arrays. The Daylight HD array produces variable- cool white (4000 to 6500K) light that imitates natural daylight. The Tungsten HD array matches conventional tungsten lighting, with adjustable warm-white (2700 to 4500K) light. They offer tint control, so they can be tweaked to perfectly illuminate individual skin tones.

Series 2 light engines work with all Source Four lens tubes to deliver a high-quality, controllable beam of LED light. For the best results, it is highly recommended that EDLT versions are used. We also offer a special LED-only version of the 50° lens tube.

FX Roadlights

The P-5 is the most well-known and reputed IP65 LED wash in the lighting industry. It has created new standards of color consistency, even coverage, light output, and smooth dynamic color balance. The P-5 employs 16bit dimming performance with no color shift, it is completely upgradeable through firmware updates, and it offers a full variety of beam angles for medium-to-longer throw applications via precise, interchangeable lenses. Its unique light projection and color mixing has made the P-5 the standard reference for lighting designers all around the world.

Optical Data
LED expected lifetime: 50,000 hours
Lightsource: 44 x high-power 10W RGBW LEDs
Native lens options: 15°, 21°, 43°

Photometric
Average CRI (CTC): 86
Color temperature range: 2000K – 10000K
Efficacy: 44 lm/W
Light output all LEDs on: 20031 lm
Light output blue: 1353 lm
Light output green: 5806 lm
Light output red: 4725 lm
Lumen per kilogram: 2251 lm / Kg
Lux @ 10m: 1993 lux
Lux @ 3m: 22142 lux
Lux @ 5m: 7971 lux
Native beam angle(s): 14° (with 15° lens), 26° (with 21° lens), 35° (with 43° lens)
Native field angle(s): 76° (with 43° lens), 55° (with 21° lens), 30° (with 15° lens

FX Roadlights

Description
Equipped with a total of forty 15 W RGBW LEDs for a massive 21,000 lm output, the Cameo ZENIT® W600 is a powerful IP65 rated wash light for demanding outdoor applications. In addition to RDM and standard DMX capability it boasts a built-in 2.4 GHz W-DMX™ transceiver by Wireless Solution Sweden AB for convenient wireless control. The fixture also provides a rich variety of stunning automated programs for standalone or wireless master-and-slave operation.

For maximum versatility, the ZENIT® W600 sports Cameo’s innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers providing a choice of 25°, 45°, 100° or elliptical 60° x 10° beam angles and a 4-way barn door are available as dedicated accessories.

Featuring advanced 16-bit technology for high-resolution colour mixing and dimming and an 18° beam spread, the ZENIT® W600 projects hugely intense, uniform washes. With colour temperature and individual LED colour correction, four selectable dimming curves and fully adjustable halogen lamp-like dimming response, the fixture is the perfect tool for highly professional lighting.

The ZENIT® W600’s die cast aluminium housing integrates three temperature controlled fans that ensure optimized, low noise operation while a bright OLED display with four touch buttons permits easy, intuitive configuration. A security lock prevents unauthorized access to the luminaire’s menu settings.

FX Roadlights

Description
Versatile, rapid installation and simple, practical configuration – the ZENIT® Z 180 G2 is the new shining star. Thanks to our innovative, patented SPIN16® technology, it is mounted in an instant using the mounting bracket’s 16-mm TV spigot and a super clamp. The powerful RDM-enabled PAR spotlight for demanding professional applications now has a bright OLED display menu. The long-lasting 180 W RGBW COB LED and 16-bit technology create consistent, high-resolution colour blends and perfect dimming response. With a range of 10° to 40°, the motor zoom provides flexible illumination ranging from sharp, narrow beams to widely spread expanses.

With its flicker-free operation via 6 selectable PWM frequencies and its IP65 classification, the ZENIT® Z 180 G2 is perfectly suited for use with film cameras or outdoors. The PAR spot also features colour temperature correction, a variable white balance and 4 selectable dimmer curves, whose response can be adjusted to simulate halogen lamps.

The ZENIT® Z 180 G2 can be controlled via 7 DMX modes or used as a master, slave or standalone unit. The bright OLED display with 4 illuminated touch-sensitive controls makes menu navigation and configuration child’s play, while an access lock prevents unauthorised setting changes. For almost silent operation, the extremely robust die-cast aluminium housing is equipped with a temperature-controlled fan. 5-pin DMX sockets and powerCON TRUE1-compatible power input and output facilitate easy parallel connection. The Cameo ZENIT® Z 180 G2 runs on all voltages between 100 and 240 volts.

FX Roadlights

B BLINDED
2x 110W LED Stage Blinder – Warm White with Amber Drift

The B BLINDED is the future of all blinders. A powerful blinder with a 2x 110W warm white LED engine, including tungsten emulation feature. The output can be compared to DWE 2x 650W but with many extra functionalities. No more dimmers, fewer cables, but more functions with faster installation and more creativity.

Furthermore, this versatile fixture is arrayable to make a 4, 6 or 8-lite blinder unit up to a 20-lite! Vertical or horizontal, it is up to your design!

• All weather use
• Extremely bright
• Strobe functions
• Refresh rate: 1.200 Hz
• DWE hot glow dimming below 10%
• Can be used for permanent lighting
• Arrayble portrait/landscape up to 10 units
• CE certified

FX Roadlights

The SIXBAR 1000™ features (12) 12W 6-IN-1 RGBAW+UV LEDs, 100,000 average hour LED life, 30° beam angle, individual control of each LED, variable dimming curve modes, strobe and chase effects, a UV wavelength of 395nm, ArtNet, KlingNet and RDM (remote device management) protocol support, 3pin and 5pin DMX, Locking Power Cable, and RJ45 in/out connections, LCD menu display with 4 button control panel, integrated dual rigging brackets, multiple unit power linking, rugged die-cast aluminum exterior, frost filter and glare shield included, flicker free operation for TV and FILM, 145W max power consumption, and a multi-voltage universal auto switching power supply (110-240v).

The COLORdash Batten-Hex 8 Linear Wash Fixture from Chauvet has eight hex-color RGBAW+UV LEDs that output any variation of white, saturated RGBA color mix and brilliant ultraviolet punch, thanks to the inclusion of UV LEDs. COLORdash Batten-Hex 8 maintains an even pixel pitch when used in multiples, either stacked in an array using the optional CBB6 bracket or lined up end-to-end. Features like a hanging bracket, floor trunnions, 3- and 5-pin DMX connectors, locking powerCON input, and power linking make the COLORdash Batten-Hex 8 a great addition to your event.

Attributes
• Versatile linear wash for a wide range of lighting applications
• Eight hex-color (RGBAW+UV) LED chips for superior color mixing
• Both simple and complex DMX channel profiles for programming versatility
• Four distinct dimming modes for easy incandescent replacement
• Lightweight – easy installation
• Tough, road-ready construction
• Silent, flicker-free operation
• Neutrik powerCON input/output connections
• 3-Pin and 5-Pin DMX input/output connections

FX Roadlights

Nexus 4×4
Nexus 4×4 is an award winning LED wash panel combining the sizzle of pixel mapping and a robust light output afforded by 16 27 W COB tri-colored LEDs. The combination of COB emitters and a clever reflector design yields a striking, diffused light richly drenched in saturated hues. Nexus 4×4 is controllable via Art-Net, Kling-Net and DMX protocols and features interlocking hardware to build large arrays. Whether in use for front viewing or as a backdrop, Nexus 4×4 promises a hard-to-match visual impact.

AT A GLANCE
Pixel-mapping RGB blinder allows you to achieve vibrant colors with bright COB LEDs
Increase pixel mapping options by controlling pixels individually
Build large arrays by linking multiple panels together with integrated locks
Works seamlessly with Nexus 2×2 and Nexus 4×1
Design with flexible control options: Kling-Net, Art-Net, or DMX
Use universal power connectors: Neutrik powerCON, Neutrik etherCON, 3- and 5-pin XLR DMX

SPECIFICATIONS

OPTICAL
Light Source: 16 LEDs (tri-color RGB) 27 W, (2 A), 50,000 hours life expectancy
Color Temperature (range): 2,800 to 10,000 K
Beam Angle: 45°
Field Angle: 75°
Illuminance (total): 484 lux @ 5 m
Pixels: 4 x 4
Pixel Pitch: 115 mm
Pixel Density: 64/m2

DYNAMIC EFFECTS
Dimmer: Electronic
Strobe Rate: 0 to 20 Hz
Standalone Color Mixing: Yes
Built-in Automated Programs: Yes
