OPTICAL
Colours: RGBW
Total LED power: 28W
Lumens: 955Lm
CRI: up to 88
Strobe: 0-25Hz
Beam Angle: 180˚
Pixels: 16

ELECTRICAL
Battery: LG Chem Lithium-ion
Battery Lifetime: 70% after 300 cycles
Battery Runtime: Up to 20 hours
Charging time (nominal): 7 Hours
Input Voltage (charger): 90-264V 47-63Hz
Input Voltage (Light): 48V 0.5A

CONTROL
Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
Range: 300m | 330 Yards
Wired DMX: not supported
Wireless DMX: CRMX & others, excluding W-DMX G5, City Theatrical

CONSTRUCTION
Housing: Polycarbonate, metal endcap
IP Rating: IP65
Relative humidity: 0-100%
Ambient Temperature: 0-40˚C | 32-104˚F
Weight: 1kg |2.2Lbs
Dimensions: Ø42 x 1035mm | Ø1.6” x H40.7”

OPTICAL
Colors: Red, Green, Blue, Mint, Amber
Total LED power: 36W
Maximum power draw: 24W
TLCI: ≥96
CRI: ≥96
Luminous flux: 1340Lm
Emittance @1m: 393Lx
Strobe: 0-25Hz
Beam Angle: 120˚
Field Angle: 180˚
Pixels: 8

ELECTRICAL
Battery: LG Chem Lithium-ion
Battery Lifetime: 70% after 300 cycles
Battery Runtime: Up to 20 hours
Charging time (nominal): 3 Hours
Input Voltage : 24V 1.25A

CONTROL
Backside Display with HSI control
Infrared
Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
Range: 300m | 330 Yards
Wired DMX: supported via Astera PowerBox
Wireless DMX: CRMX & others, excluding W-DMX G5, City Theatrical

CONSTRUCTION
Housing: Polycarbonate, metal endcap
IP Rating: IP65
Relative humidity: 0-100%
Ambient Temperature: 0-40˚C | 32-104˚F
Weight: 0.765kg | 1.68Lbs

Dimensions: Ø42 x 550mm | Ø1.6” x H21.7”

OPTICAL
Colors: Red, Green, Blue, Mint, Amber
Total LED power: 144W
Maximum power draw: 92W
TLCI: ≥96
CRI: ≥96
Luminous flux: 5800Lm
Emittance @1m: 1570Lx
Strobe: 0-25Hz
Beam Angle: 120˚
Field Angle: 180˚
Pixels: 32

ELECTRICAL
Battery: LG Chem Lithium-ion
Battery Lifetime: 70% after 300 cycles
Battery Runtime: Up to 20 hours
Charging time (nominal): 3 Hours
Input Voltage : 24V 4A

CONTROL
Backside Display with HSI control
Infrared
Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
Range: 300m | 330 Yards
Wired DMX: supported via Astera PowerBox
Wireless DMX: CRMX & others, excluding W-DMX G5, City Theatrical

CONSTRUCTION
Housing: Polycarbonate, metal endcap
IP Rating: IP65
Relative humidity: 0-100%
Ambient Temperature: 0-40˚C | 32-104˚F
Weight: 2.90kg | 6.39Lbs

Dimensions: Ø42 x 2031mm | Ø1.6” x 79.9”

OPTICAL
Colors: Red, Green, Blue, Mint, Amber
Luminous Flux: 750lm*
Total LED power: 14W
Max power draw: 10W
TLCI (3200-6500K)*: ≥96
CRI (3200-6500K)*: ≥96
Strobe: 0-25Hz
Beam Angle: 120˚
Field Angle: 180˚
Pixels: 1
(* Typical value)

ELECTRICAL
Each bulb allows AC and DC power
AC Power: FP5-E26: 100-120 VAC, FP5-E27: 100-240VAC
DC Power: 5-18VDC, 2.1A via DC socket

CONTROL
Setup Via AsteraApp or Battery Base
Wireless Modules: UHF, CRMX, Bluetooth
DMX: Wireless DMX (CRMX)
Range
UHF: 100m | 110 Yards
CRMX: 100m | 110 Yards
Bluetooth: 3m | 3 Yards

CONSTRUCTION
Housing: Aluminium + polycarbonate
Ingress Protection: IP44
Relative humidity: 0-100%
Ambient Temperature: 0-40˚C | 32-104˚F
Weight: 0.24kg | 0.53Lbs

Dimensions: Ø70 x 130mm | Ø2.76” x H5.12”

OPTICAL
Colours: RGBAW Philips Lumileds
CRI: 92
Total LED power: 45W
Luminous Flux: 1340Lm
Emittance (@2m): 4800Lx
Strobe: 0-25Hz
Beam Angle: 13 ˚
Pixels: 1

ELECTRICAL
Battery: LG Chem Lithium-ion
Battery Lifetime: 70% after 300 cycles
Battery Runtime: Up to 20 hours
Charging time (nominal): 5 Hours
Input Voltage: 90-260V 50-60Hz

CONTROL
Wireless Modules: 865-870MHz | 902-928MHz | 2.4GHz
Range: 300m | 330 Yards
Wired DMX: supported via 5-pin XLR in and out sockets
Wireless DMX: CRMX & others (excluding W-DMX G5, City Theatrical)

CONSTRUCTION
Housing: Aluminium
IP Rating: IP65
Relative humidity: 0-100%
Ambient Temperature: 0-40˚C | 32-104˚F
Weight: 3.40kg |7.5Lbs
Dimensions: 145 x 190 x 221 (mm)

OPTICAL
Order Code: PB15
LED Engine: Titan LED Engine
Colors: RGB Mint Amber
Total LED Power: 15W
Power Draw: 12W
Light output: 2700K, 3200K, 5500K:* 388lm, 450lm, 375lm
CRI(Ra)/TLCI 3200-6500K*: ≥96
Beam Angle: 13°
Strobe: 0 – 25Hz
Pixels: 1
*Typical value

ELECTRICAL
Battery Lifetime: 70 % after 300 cycles
Battery Runtime: up to 20 hours
Charging Time (nominal): 4 hrs
Input Voltage: 24VDC
Input Current: 0.8A

CONTROL
Wired DMX: Yes (via PWB-2-86)
CRMX Receiver: Built-in
Wireless Frequencies: CRMX 2.4GHz, UHF, Bluetooth
Range (m/yds): 300 / 330yds

CONSTRUCTION
Housing: Aluminium
IP Rating: IP65
Ambient Temperature (°C/°F): 0°- 40° / 32°- 104°
Weight (kg/lbs): 1.12 kg / 2.47 lbs
Dimensions (mm/inches): 91 x 91 x 94 / 3.6 x 3.6 x 3.7

Description
With built-in wireless DMX, battery operation and IP65 rating, the Cameo ZENIT® B200 is ready for demanding indoor and outdoor lighting applications. The highly professional wash light is equipped with twenty-one 15 W RGBW LEDs with a 50,000 hour lifetime and powerful 6,600 lm output for brilliant, uniform colours. A polyethylene and tempered glass lens provides a 21° beam spread.

For maximum versatility, the ZENIT® B200 sports Cameo’s innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers and a 4-way barn door are available as dedicated accessories.

In addition to RDM, seven modes of DMX and IR remote or manual control via the fixture’s display the ZENIT® B200 incorporates a 2.4 GHz W-DMX™ transceiver. Developed by Wireless Solution Sweden AB, W-DMX™ has become the inofficial standard for professional wireless lighting control. The luminaire’s super capacity lithium-ion battery is providing reliable RGBW mode performance up to 24 hours from a single charge, and the smart battery management system prevents overcharging and exhaustive discharge for extended battery life.

Sporting six selectable PWM frequencies up to 25,000 Hz and convection cooling for flicker-free and noiseless performance, the ZENIT® B200 is perfectly suitable for motion picture and TV applications. It utilises high-resolution 16-bit colour mixing and dimming and includes a choice of dimming curves with adjustable response plus temperature correction. The aluminium housing features a bright 4-button OLED display for easy configuration. The ZENIT® B200 can also be used for emergency lighting when connected to a DC outlet and comes with an IR remote control, omega mounting bracket and power cord.

The combination of battery power and wireless DMX control makes them truly portable, enabling extremely fast setup with no cables, thus creating a safer and more attractive environment. The unit’s aluminium casing blends into any décor and can be enhanced with additional optional shrouds in any colour including stainless steel mirrored finish.

CORE Lighting’s battery powered wireless uplighters are known for their style, rugged outdoor IP rating and their brightness. In this case a 1,200 lumen 40W dual chip RGBW output.

Where the full ColourPoint unit is capable of lighting up to 4-5 storeys, the ColourPoint Mini is aimed towards smaller 2-3 storey venues, as with the majority of hotel function suites, marquees tents, party venues and small trees.

The unit can smoothly wash walls, provide temporary lighting to architectural details and beautifully light the insides of marquee tents and rooms.

ColourPoint Mini is available in a lightweight charging case to allow for fast and easy transport of the products, along with convenient recharging between uses.

All ColourPoint & Mini battery-powered wireless uplighters come equipped with Wireless Solution industry leading Wireless DMX built in and can either operate wirelessly from a Wireless DMX transmitter unit, or from a ColourPoint unit set to ‘Master’ or in stand-alone mode,. All units in stand-alone mode can operate independently with built-in set colours matched to Lee filters or alternatively run their own internal routines.

Lightweight lithium battery powered Mk2 LED event uplight with Wireless DMX Control, rated for outdoor use (IP65). Very bright 1200 lumen 40W output will light up small trees, 3-storey architectural uplighting and wall-washing in marquees & buildings.

The units connect wirelessly with Wireless DMX to other CORE fixtures to avoid the need for complex lighting desks on-site. Or they can also be linked up to a W-DMX enabled lighting desk for more complex schemes, or simply run as stand-alone units with built-in colours (Lee filter reference).
